4.8 Properes of sensor tracks
The properes of the sensor tracks and the feedback number are assigned to the reversing loop here.
1
2
3
4
5
6 7 8 9
1) Switch-o delay Feedback in ms.
2) turnout mode
Mode how the turnout address is used.
O No acon.
3) Follow The polarity of the reversing loop follows the posion of the
turnout.
Set S1 and S2 set the turnout.
Both Both (Follow, Set) opons are considered
4) Turnout status
Condion of the turnout when the reversing loop is in its inial posion.
5) Closed Posion of the turnout straight
6) Thrown Posion of the turnout curved
7) Feedback number Sensor track 1 (S1)
(Sensor track for polarity switching)
8) Feedback number Sensor track (S0)
(Reversing loops Enter entry indicator *oponal* if not used Feed-
back indicator number "0".)
10 11
6) turnout address Entrance turnout of the reversing loop
7) Feedback number Sensor track (S3)
(Reversing loops Enter entry indicator *oponal* if not used Feedback in-
dicator number "0".)
8) Feedback number Sensor track 2 (S2)
(Sensor track for polarity switching)
9) Feedback number Reverse loop track (T)
10) Accept current sengs.
11) Cancel
12) First switch (1.magnec arcle address) to be addressed.
seng:
0 = Roco® (shi of magnec arcle addresses +4)
1 = Magnec arcle addresses Standards-compliant to RCN 213
(default seng!)
13) turnout posion indicator
14) These arrows symbolize the entry or exit into the reversing loop.
15) These points indicate which feedbacks have triggered.
