4.9 Features Global Detector
Here the properes of the Global Detector are assigned to the reversing loop. The Global Detector comprises the secons S1, S2 and T of the reversal loop.
1) Detector input on the module. (If a check mark is removed here, the corresponding detector is deacvated).
2) Feedback address of the normal occupancy detector (current sensor).
3) Block number linked to the detector output (Railcom® detector).
4) Switch-o delay of the feedback devices.
5) The DR5013 detects the track direcon of the locomove.
With this opon you can reverse the direcon.
6) Accept current sengs.
7) Cancel
1 2
3
4
5
6 7
