14
DS6 User Manual
1. HARDWARE / PSU interface
DS6 PSUs can be formed into a stack
(maximum of 2 DS6 PSUs) in order to accom-
modate larger lighting configurations.
A stack of PSUs is always controlled by the
PSU on top.
The same process when mounting any
Communication Handle also applies to stacking.
Remove the communication handle from
the bottom PSU. Place the top PSU on the
PSU with the removed handle and tighten
the bolt using hex key No.5
A LED light indicator will show what status
the PSU is in. Green LED is for master PSU
and Orange LED is for Slave PSU
The top PSU will control all parameters and
save settings for the whole stack.
When unstacked, the slave PSU will run on
the settings saved prior to being stacked.
