DN-16032 USER’S GUIDE PAGE 23/61 Rev. PV1.0
七. IP-CAM Network Framework Installation 7
Way to access Internet Use Permanent ADSL or Cable Modem
Physical IP Address Owns one physical IP address
IP Share or LAN Hub Must be equipped with DHCP and NAT
functions
Network Setup for IP -CAM LAN Enable / Manually
Web Server Port Number, need to be
configured
Suitable Objects Users with one fixed physical IP, IP Share
and several IP-CAMs installed
1. Set a real physical IP address (e.g., 211.78.174.01) for the public IP of IP Share.
Then, set another private IP address and activate the DHCP server function of IP
Share.
2. In the IP configuration for each IP-CAM, please assign different virtual IP address
internally and respectively. In the Http Port setting, please specify different port
parameters. (Please refer to 2.4-1 STATIC - IP Address Settings to fill in the IP
address properly.)
3. For the port transformation in IP Share, please refer to IP and port settings of camera
to configure accordingly.
4. For viewing images in IP-CAM from remote computer: Open IP browser and type in
the IP address of IP Share and the port number of IP-CAM, e.g., http://
211.78.174.01:1025.
