Dillon AFG Series User Manual

13
The communications mode allows you to set the
options pertaining to the RS-232 and MITUTOYO
ports and also the choice of sending displayed
readings to either port, or to the internal memory
store.
Access the COM mode by following the steps in
the section Selecting a Mode of Operation. After
entering the COM mode, the current baud rate
setting will be displayed.
1. With the baud rate setting
displayed, press the UP or
DOWN key to display one of the
following baud rates:
1200
9600
19200
57600
With the baud rate
you want displayed,
press the MORE
key. . . The baud rate is
entered into memory
and the current format
choice is displayed.
2. Press the UP or
DOWN key to
display one of the
following formats
in which values can
be transmitted:
PLAIN The value is transmitted
as a numeric string with
no units.
Communica-
tions Mode
Format
Baud Rate
The baud rate only
applies to the RS-
232 port and the
same rate is used for
both transmit and
receive lines.
If the mode has been
previously viewed, the
display will show the
last parameter
viewed. Press the
MORE key to scroll
through the list of
parameters until you
see the one you
want.
