DIMOEL KIT BATT12V - Page 25

23
PARTS LIST
9
10 11 12 13
8
7
6
5
Ref Part name Q.ty
1Electromechanical actuators 12VDC 2
2 Control unit PRG12PP 1
3Transmitters TRC-4 DM 2
4 Flasher EGG12 1
5 Fastening bracket, actuator to pillar 2
6 Fastening pin, actuator 2
7 Fastening Seeger, pin 4
8 Fastening bracket, actuator to shutter 2
9 Clamp cylinder 2
10 Plastic washers 4
Spare plastic washers 4
11 M10 nut 2
12 M10 washer 2
13 M10 x 40 screw 2
14 12V - 4,2Ah Battery 1
