Dimplex CAS500R - Page 10

9
Dim A 300mm
Dim B
Min: 190mm
Max: 260mm
MODEL DIM ‘A’
CAS500R 508mm
CAS1000R 1017mm
FUEL BED DIM ‘B’
METAL 304mm
LOG 354mm
>210cm
2
Eg. 42cm x 5cm
>210cm
2
Eg. 14.5cm x 14.5cm
Fig.2
Fig.3
Fig.1
400mm
400mm
400mm
