16 www.dimplex.com
Operation
D i sp lay
General Operation
WARNING: The Revillusion
®
Built-in Electric Firebox must be installed properly before it is used.
The hidden touch controls are located on the upper center of the replace.
To operate correctly, the remote control must be pointed toward the hidden touch controls. The remote control has a
range of approximately 30 ft (9 m).
!
NOTE: The heating element remains hot after shutdown. When the heat is turned off, there is a 2-minute cool
down period before the fan shuts off completely.
!
NOTE: The replace will retain the previously used settings after a power interruption.
Figure 16
Figure 17
Indi c at or L i g h t s
