Preconfiguration of the Heat Pump Heating System 5.2
English
5.2 Menu
The preconfiguration menu can be accessed by:
 Simultaneously pressing (for approx. 5 seconds) the button
combination (ESC) and (MENU).
 The preconfiguration is exited via the (ESC) button.
Abbreviations:
The following presettings must be carried out:
HP Heat pump
AW HP Air-to-water heat pump
BW HP Brine-to-water heat pump
WW HP Water-to-water heat pump

Preconfiguration of all system components
for dynamic menu structuring
Setting range Display

Monovalent (heat pump as sole heat generator),
mono energy (heat pump and immersion
heater), bivalent-parallel (heat pump and
boiler), bivalent-alternative (heat pump or
boiler), bivalent-renewable (heat pump or
renewable heat source)
Monovalent
Mono energy
Bivalent-parallel
Bivalent-alternat.
Bivalent-renewable
Always

Is an internal or external thermal energy meter
(WMZ 25 or WMZ 32) present in the system?
The thermal energy meter emits a pulse of at
least 2 seconds per kWh. The pulses are added
together depending on the mode of operation.
No
Yes
WPM 2006/2007


Is the additional heat exchanger that is
integrated into the heat pump connected for
waste heat recovery (DHW / swimming pool)?
No
Yes
Reversible HP


Is an external thermal energy meter (WMZ25 or
WMZ32) available for domestic hot water or
swimming pool water preparation via the
additional heat exchanger?
No
Yes
WPM Econ
Reversible HP
desuperh.


Are several heat pumps running parallel in a
network? (Observe the operating instructions for
parallel connection!)
No
Yes
Always


Is the master controller to take on a central or
decentralised function in network operation in
relation to swimming pool water and DHW
preparation? (Observe the operating
instructions for parallel connection!)
central
decentralised
Parallel connection
Master function

Is a four-way valve present in the heating
circuit? (Observe the installation instructions for
four-way valves!)
without (
cooling +
heating
)
with (
cooling + heating)
without (
heating only)
Reversible HP

How is the flow through the heat pump's
liquefier implemented in the heating circuit?
with M13
with M16
Reversible HP


Is the active cooling function of the reversible
heat pump used?
Yes
No
Reversible HP


Is a passive cooling controller connected to the
heating controller?
No
Yes
BW or WW HP


Is a 2 or 4-pipe system used for passive
cooling?
2-pipe system
4-pipe system
BW or WW HP
Passive cooling function

Is heating circuit 1 in the system only used for
heating, or is it also used for dynamic or silent
cooling?
Heatin
Heating/silent
cooling
Heating/dyn.cooling
Always

Does the system have a 2nd heating circuit in
which a mixer is controlled?
No
Heating
Haeting/silent
cooling
silent cooling
HC1 Heating
or HC1
Heating/dyn.cooling
