Dimplex WPM EconPlus - Special Functions

EN-21
Configuring the Heat Pump Heating System 6.4
English
Table 6.1: Switching mode of pressure switches for heat pumps with a
manufacturing date before FD8404
6.4 Special Functions
Depending on the system configuration, the “Special functions”
menu contains the following options for changing the current
operating states:
ATTENTION!
Special functions must only be activated by a technician in order to carry
out a start-up or an analysis of the heat pump system.

“Contact open” denotes a utility block. Always

“Contact open” denotes a block. Always


“Contact closed” means that a fault has occurred. LP brine

“Contact closed” means that a fault has occurred. Cooling function
Silent cooling


“Contact closed” means that a request for domestic hot water is
pending.
Domestic hot
water
Thermostat


“Contact closed” means that a request for swimming pool water is
pending.
Swimming pool

“Contact closed” denotes circulation pump start. Circulation
Pulse
1. Valid for all heat pumps with a manufacturing date after FD8404. All other heat pumps should be set according to the following table:

Status display of all digital inputs
Heat pump
type
High-pressure
switch
Low-pressure
switch
LI / LA NO contact NO contact
SI / WI NO contact NC contact
High-temperature NO contact NC contact

Activation of special functions Display

By activating the “Quick start” function, the heat
pump can start up after the safety-related periods
have elapsed. A switching cycle block is
overridden.
No
Yes
Always

When the “Deactivate operating” function is
activated, the heat pump can start up after the
safety-related periods have elapsed. The lower
operating limit undershoot monitor is turned off.
No
Yes
Brine-to-water HP

By activating this function, defrosting is disabled for
one hour in the case of air-to-water heat pumps.
The 2nd heat generator is enabled. If defrosting is
taking place, it will be terminated.
No
Yes
Air HP

Function testing of pumps and mixer Always


By activating this function, the primary side pumps
are switched on constantly for a period of 24 hours.
The heat pump remains blocked during this period.
No
Yes
Always


By activating this function, the secondary side
pumps are switched on constantly for a period of 24
hours. The heat pump remains blocked during this
period.
No
Yes
Always


By activating this function, the hot water pump is
switched on constantly for a period of 24 hours.
The heat pump remains blocked during this period.
No
Yes
Always


By activating this function, the mixers in the system
are firstly moved in an OPEN and then in a
CLOSED direction for the set mixer runtime
No
Yes
Always
