Dimplex WPM EconPlus - Coding

EN-10
5.3
English
5.3 Coding
Following resumption of the power supply, the controller
automatically identifies the type of heat pump connected. A
special coding resistance is installed in every heat pump for this
purpose, according to the following table:
ATTENTION!
An air-to-water heat pump with defrosting via reverse circulation is only
identified if no sensor is connected to input N1-J6/B7. (Flow temperature
limit for BW or WW HP)
NOTE
Before setting the heat pump manager, check the heat pump type code in
the “Operating data” menu. Coding is defined when the voltage is
recovered. If the message “Coding, HP fault” appears in the display, the
(ESC) button must be pressed.

Does the system have a 3rd heating circuit in
which a mixer is controlled?
No
Heating
Heating/ silent
cooling
silent cooling
Heating circuit 2

Is DHW heating carried using by the heat
pump?
No
Yes
Always


Is a sensor or thermostat used to regulate DHW
heating?
Sensor
Thermostat
Domestic hot water


Has a flange heater for reheating and thermal
disinfection been installed in the DHW cylinder?
No
Yes
Domestic hot water
Sensor


Is a circulation pump present? No
Yes (pulse)
Yes (time)
Domestic hot water


Is the heat pump used for heating swimming
pool water?
No
Yes
Always



Is a sensor or thermostat used to regulate the
heating of swimming pool water?
Thermostat
Sensor
Reversible HP


Is a pressure switch installed for monitoring the
brine pressure?
No
Yes
BW HP with integrated
controller

Should the activation of the brine controller be
indicated on the display, or should the heat
pump and primary pump be switched off?
Display
Switch-off
BW or WW HP
Low-pressure brine

Preconfiguration of all system components
for dynamic menu structuring
Setting range Display
Heat pump type
Coding resistor
Controller with removable control panel
Air-to-water heat pump with defrosting via reverse circulation 
Brine-to-water or water-to-water HP (display for HP with wall-mounted
controller)
0 
Brine-to-water HP (display for HP with integrated controller) 40.2 k
Water-to-water HP (display for HP with integrated controller) 49.9 k
High-temperature air-to-water HP 63.0 k
Reversible air-to-water HP 28.7 k
Reversible brine-to-water HP 19.6 k
Air-to-water HP with hot gas defrosting 14.7 k
