Dimplex XHD23 User Manual

11
Flame LED Strip Replacement
Tools Required: Phillips head screwdriver
WARNING: If the rebox was operating prior to
servicing, allow at least 10 minutes for the heating
elements to cool o󰀨 to avoid accidental burning of skin.
WARNING: Disconnect power before attempting any
maintenance to reduce the risk of electric shock or injury to
persons.
1. Follow the instructions for accessing the bottom
components on pages 8-9.
2. Locate the plastic LED holder bar and remove the
screw on either side (2 total). (Figure 7)
3. Disconnect the wire(s) that are connected to the LED
strip(s) on the LED holder. The LED holder can now be
removed.
4. Remove the 4 screws that secure the LED strip to the
LED holder. (Figure 6)
5. Install new board by reinserting the screws and
connecting the cable(s).
6. Properly orient and install the LED holder, ensuring that
the ame LEDs are facing the icker rod.
7. Reassemble the rebox.
Flame Base LED Strip Replacement
Tools Required: Phillips head screwdriver
Flathead Screwdriver
WARNING: If the rebox was operating prior to
servicing, allow at least 10 minutes for the heating
elements to cool o󰀨 to avoid accidental burning of skin.
WARNING: Disconnect power before attempting any
maintenance to reduce the risk of electric shock or injury to
persons.
1. Follow the instructions for accessing the bottom com-
ponents on pages 8-9.
2. Locate the plastic LED holder bar and remove the
screw on either side (2 total). (Figure 7)
3. Disconnect the two cables that lead to the LED strips.
4. The LED holder can now be removed
5. Release the LED strip from the clips: starting at one
end of the LED strip, carefully place the head of the
athead screwdriver under the LED strip while gently
pulling it up and out to release it from the clips on the
LED holder.
6. Snap the new LED strip into place and reconnect the
cable. (Figure 6)
7. Connect both cables. Properly orient and install the
LED holder, ensuring that the ame base LEDs are
toward the base of the rebox and the ame LEDs are
facing the icker rod.
8. Reassemble the rebox.
Media Tray / Media LED Strip Replacement
Tools Required: Phillips head screwdriver
WARNING: If the rebox was operating prior to servicing, allow at least 10 minutes for the heating elements to cool
o󰀨 to avoid accidental burning of skin.
WARNING: Disconnect power before attempting any maintenance to reduce the risk of electric shock or injury to
persons.
1. Follow the instructions for removing base panel
2. Remove the 2 screws that secure the media LED lights and unplug the board.
3. Align the new board, ensuring that the connector with the marking IN is oriented toward the right-side so that the cable
can be reconnected on the correct side. Ensure that the LED lights on the strip are facing the clear plastic face of the
tray.
4. A󰀩x the LED strip to the media tray, ensuring that the plastic washers are placed between the LED strip and the
screw.
Figure 6
Flame LED Strip
Flame Base LED Strip
