Fireplace Installation
• Connect the L2 wire from the
unit to the L2 wire from the
power supply with a wire nut.
• Connect the N wire from the
unit to the neutral wire from the
power supply.
• Connect the G wire from the
unit to the ground wire from the
power supply with a wire nut
or attach the grounding wire
to the cover with the provided
grounding screw, by placing
the wire in-between screw
and lock washer and tighten
(Figure 3).
• Ensure that all wires are
secure and do not protrude
past the ame panel, so as
not to be visible after nal
assembly.
• Continue to the nal assembly
instructions.
For Bathroom Use
If this unit is installed in a bathroom
it must be protected by a GFI
receptacle or circuit. If receptacle is
used it must be readily accessible.
To prevent electrical shock this
unit is an electrical appliance
that is NOT watertight and must
be installed as to prevent water
from entering unit. This must be
installed away from showers, tubs,
etc. Never locate replace where
it may fall into a bathtub or other
water container.
