Final Assembly
1. Locate and remove the 12
screws securing the partially
reflective glass bracket to
the unit, along the top of the
opening, and set bracket and
screws aside.
2. Remove the provided suction
cup from the inside cavity of the
unit (only for XLF74 and XLF100
units).
3. Before installation ensure that
the front glass and the partially
reective glass are clean.
Particles can be removed by
dusting lightly with a clean dry
cloth. To remove ngerprints
or other marks, the glass
can be cleaned with a damp
cloth. Ensure that the glass
has completely dried before
installation.
4. Carefully secure the suction cup
to the partially reflective glass,
reflective side out, and place
into the openings on either side
of the unit.
5. Tip the glass into the unit and
using the removed screws
secure the glass into the unit
with the provided bracket
(Figure 6). Remove the
suction cup.
6. Evenly space the large media
in the media tray along the back
of the media tray (for optimum
media effect), then carefully
pour and evenly distribute
the smaller media into the Media
Tray.
7. Carefully place the front glass
into the lip located at the bottom
of the opening of the firebox.
8. Tip the front glass into the unit
and secure using the provided
screws and Allen key. (Figure 7).
!
NOTE: Ensure that the suction
cup and Allen key are kept for
any future maintenance
or
service.
Fireplace Installation
