Quick Reference Guide
1. The electrical information
regarding your electric
replace can be found on the
rating label located on the top
of the unit.
Please use our convenient online
registration page to record your
model and serial numbers for
future reference at
www.dimplex.com/register
2. If you have any technical
questions or concerns
regarding the operation
of your electric replace,
or require service contact
customer service at
1-888-346-7539.
3. For dimensions of your
replace, refer to Figure 1.
Figure 1
16.49 in
419 mm
15.82 in.
402 mm
15.00 in.
381 mm
5.79 in.
147 mm
4.34 in.
110 mm
XLF50 50.31 in [1278 mm]
XLF74 74.31 in [1887 mm]
XLF100 100.31 in [2548 mm]
XLF50 51.41 in [1306 mm]
XLF74 75.41 in [1941 mm]
XLF100 101.41 in [2576 mm]
