6 Diagnostics and switching status displays
SAFEONE DN3PD2 Manual 20
6 Diagnostics and switching status displays
The safety switchgear indicates its operational readiness and the status of the enabling current
path by the two-color LEDs "OK" and "SPEED". See table
The red flashing LED "OK" indicates an error.
The green flashing LED "SPEED" indicates the expiry of a time constant.
6.1 LED indicators
Legend
LED on
LED off
LED flashing
LED OK
LED
SPEED
Flash-
code
13/14,
23/24
Status
--
ON
acknowledged
in range
--
OFF
not acknowledged
out of range
2
ON
acknowledged,
start-up monitoring
active
out of range
