DINA SAFEONE DN3PD2 - Diagnose

7 Configuration
SAFEONE DN3PD2 Manual 27
7.10 Diagnose
Die Diagnose bietet folgende Funktionen:
1
Diagnosis start / stop
Start or stop the diagnosis
2
Movement/time diagram
For visual representation of the movement:
blue line: actual frequency
red lines: fmin and fmax
2a
Unit switching
Representation of the actual and limit values in
Hz or corresponding speed unit.
3
Status display of the input and output
13/14, 23/24: Status of the enabling current
path
O1: Status the output O1
O2: Status the output O2
Q: Status of the input Q
4
Help and error list
Help texts and occurred errors
5
Latch Data
Read out switch-off relevant data
- Actual frequency
- States of the outputs/input
- advanced mode for service
6
Device ID
Hardware and Firmware information
Validation
See chapter „Validation“
