DINA SAFEONE DN3PD2 - Configuration

7 Configuration
SAFEONE DN3PD2 Manual 22
Check whether the start signal is within the
time range of min. 200ms to max. 10s.
4 x flash
open-circuit on U, V, W
Check the wiring at the measuring inputs for
 short circuit
 cross-connection
 wire break
5 x flash
transmission error password
The password was not confirmed. Transfer
the password again.
6 x flash
Relay error
Send the device to DINA Elektronik for test-
ing.
7 x flash
single-channel error
The signals at the measuring
inputs are different
Check the wiring at the measuring inputs for
 short circuit
 cross-connection
 wire break
8 x flash
Frequency > 1500Hz
Check the frequency at the measuring in-
puts
9 x flash
internal error
Send the device to DINA Elektronik for test-
ing.
10 x flash
internal error
Send the device to DINA Elektronik for test-
ing.
7 Configuration
The configuration of the DN3PD2 safety switchgear is made via the configuration soft-
ware GO:BEYOND.
The parameterization of the DN3PD2 is described in the following chapters.
WARNING
Danger through incorrectly set parameters
Incorrectly set parameters for motion monitoring can lead to dangerous machine or
system states.
 Make sure that the parameters entered or selected in the software corre-
spond to the connected hardware.
 Carry out a function test after parameterization and after every change in
the parameterization as part of the validation.
Note
Assistance during validation and commissioning can be a separate measuring device
or the diagnostic function (display of actual and limit values) in conjunction with the
validation function in the configuration software.
The diagnostic function is not safety-related.
