7 Configuration
SAFEONE DN3PD2 Manual 25
7.5 Parameterization
You can make the following settings on the configuration software
Parameter
Range
Note
COM-Port
Password
maximum 8 signs
fmax *)
0.5 - 1200 Hz
At ID-Nr. 34PD03:
>30Hz – 1200Hz
fmin *)
0.5 - 1200 Hz
deselectable
At ID-Nr. 34PD03:
>30Hz – 1200Hz
Acknowledgment
- manual
- automatic
Automatic acknowledgment
with start-up monitoring:
fmin ≥ 1.1 Hz
Start-up monitoring
0-60s
0 ≙ only range-monitoring
Switch-off delay
0-2s
Switch-on delay
0-10s
Project name
maximum 8 signs
absolutely necessary
Author
Is not transferred to the
device.
Date
mm.dd.yy
Advanced settings
Frequency threshold
16 steps
Number of measuring cy-
cles
1-4
sensitivity
Modus 1-4
Machine data
Axis type
Linear axis, spindle, rotary axis
Number of pole pairs
1-99
Ratio
0.01-99999
Radius
1-9999
Pitch
0.001-9999
Minimum speed
Depending on the machine
data and the permitted
maximum frequency.
Maximum speed
*)
 To determine the switching thresholds, the number of pole pairs must be taken into ac-
count: f [Hz]= (n [U/min] / 60) x number of pole pairs
Example: 5000 rev/min x 3 (number of pole pairs) / 60 = 250Hz
 Asynchronous motors have a load-dependent slip between the motor speed and the ro-
tating field frequency. This must be taken into account when parameterizing the thresh-
old frequencies (fmin and fmax).
