DINA SAFEONE DN3PD2 - Signal Outputs; Contact Outputs; General Data

10 Technical data
SAFEONE DN3PD2 Manual 33
Measurement uncertainty
1%
Switching hysteresis
10%
10.4 Signal outputs
Outputs
O1, O2
Non safety
Voltage range
UB-1V
Switching current
≤ 100mA
shot-circuit and overload protection
10.5 Contact outputs
Outputs
13/14, 23/24
Contact material
AgSnO
2
Output guidance
Minimum switching current
10 mA
Maximum switching current
6 A
Switching capacity in accordance
with IEC 60947-5-1
DC13: 4A/24V
AC15: 5A/230V
Mechanical service life
10
7
switching cycles
Contact fuse
6 A gL/gG
Typical response time
Number of measuring cycles x (period (re-
ciprocal value of the set frequency) + max.
2ms cycle time) + max 10ms relay switch-on
time
10.6 General data
Type of protection (housing and terminals)
IP 20
Type of protection (place of installation)
min. IP 54
Clearance and creepage distances
In accordance with DIN EN 50178
