Specification
mode. Start approximately 8 m from starting point so that the unit is at maximum speed when
starting the test. Results should be recorded for a 60 m course. Drive Forward, record time. Drive
Reverses, Record Time.
Drive (Above Horizontal): Test should be done on a smooth level surface. Drive Select Switch
should be set to low speed mode. This verifies that the switches are working when the boom is
above horizontal. Results should be recorded for a 15 m. course. Drive Forward, Record Time.
Drive Reverse, Record Time.
Platform Rotate: Platform level and completely rotated one direction. Rotate the opposite
direction, Record Time. Rotate the other direction, Record Time.
Articulating Jib: Platform level and centered with the boom. Start with the Jib down. Jib Up,
Record Time. Jib Down, Record Time.
Test Notes
1 Stop watch should be started with the function, not with the controller or switch.
2 Drive test results reflect 315/55D-20 tires.
3 All speed tests are run from the platform. These speeds do not reflect the ground control
operation.
4 The platform speed knob control must be turned to rapid position.
5 Function speeds may vary due to cold, thick hydraulic oil. Test should be run with the oil
temperature above 100° F (38° C).
6 Some flow control functions may not work with the speed knob clicked into the creep position.
Oil and Coolant Fluid Capacity Table
grease or oil for
lubricating rotating parts
refer to the chapter of lubrication
Fill the hydraulic tank with the oil as
the customer command. But the
hydraulic tank would be filled with
L-HM46, without special command.
Attention, the customer should
confirm to change the oil according
to the local environment
