DINGLI BT22ERT - Performance Specification

Specification
13
Gross Machine Weight
13200kg
Ground Clearance
0.28m
Battery
Type
lithium battery
Capacity
420Ah
Nominal Voltage
80V
Tire and Wheels
Type
Foam Filled Tire And Wheel
Model
315/55D-20
Outer Diameter
848mm
Width
319mm
Performance Specification
Driving Speed (Boom Stowed, high range) (km/h)
6
Driving Speed (Boom Raised or Extended) (km/h)
1.1
Boom Lift Up (s)
60～75
Boom Lift Down (s)
55～70
Swing Right & Left (Fully retracted) (s)
130～160
Telescope Extent Out (s)
48～55
Telescope Retract In (s)
48～55
Jib Up (s)
24～36
Jib Down (s)
22～34
Platform Rotate R & L (s)
10～15
Machine Orientation When Doing Speed Tests
Lift: Boom Retracted. Telescope Retracted. Lift Up, Record Time, Lift Down, Record Time. The
result will be different when the boom is fully extended.
Swing: Boom at lifted position. Telescope Retracted. Swing the Turntable to the end stop, Record
Time. Swing the Opposite Direction, Record Time. Telescope extended, repeat it above.
Telescope: Boom at Full Elevation; Telescope Retracted; Telescope Out, Record Time.
Telescope In, and record Time.
Drive: Test to be done on a smooth level surface. Drive Select Switch should be set at high speed
