Operating Instructions
39
Class B
Item
Fault
Restriction logic
1
moving joystick fault
1 restrict moving, showing code 46
2 moving joystick initialization fault after restarting
up system, restrict moving and show code 36
2
main boom telescopic joystick
fault
1 restrict main boom telescopic operation,
showing corresponding faulty code.
2 telescopic joystick initialization fault after
restarting up system, restrict telescopic and
show code 36
3
main boom lifting joystick fault
1 restrict main boom lifting operation, showing
corresponding faulty code.
2 lifting joystick initialization fault after restarting
up system, restrict lifting and show code 36
4
jib lifting joystick fault
1 restrict jib lifting operation, showing
corresponding faulty code.
2 jib lifting joystick initialization fault after
restarting up system, restrict jib lifting and show
code 36
5
turret rotation joystick fault
1 restrict turret rotation, showing corresponding
faulty code.
2 turret rotation joystick initialization fault after
restarting up system, restrict turret rotation and
show code 36
Class C
Item
Fault
Restriction logic
1
PVG fault
1 No restriction.
2 Show corresponding faulty code.
2
chains broken switch
1 Restrict main boom extending out, showing
code 51
Lower the platform by activating bypass button on ground console or platform console, and then
operating corresponding operation, when there is one fault or more belonging to class B or class
C.
