DINO RXT
4.3.17. Test loading
DANGER
WARNING
CAUTION
NOTICE
The correct operation of outreach- and overload limit switches RK4 and RK5 must be
done before test loading!
(I)
1. Place the lift on an even surface with good carrying capacity. Drive the outriggers to their
lowestposition(theminimumsupportwidth).
2. Raise the boom, turn it to the side from the transport support and lower it to the ground.
3. Putaweighedloadof215kgontheplatform(I).
4. Lifttheboomtoashighasitgoesandextendthetelescopetoitsfulllength(maximum
liftingheight).
5. Lower the boom until the safety device stops the movement.
6. Turntheboomroundover360°.
7. Retract the telescope and lower the boom to a horizontal position.
8. Extend the telescope until the safety limit switch RK4 stops the movement.
9. Compare the outreach with the reach diagram. If necessary, readjust according to the
instructions“Adjustmentoftheoutreachandoverloadlimitswitches”(seepoint“Regular
servicing”).
10. Establishthestandingstabilityinthissituationbyturningtheliftroundover360°.
(II)Carryoutthesameprocedurewithaplatformloadof80kg
Check the structures after test loading.
Aftertheabovementionedtestloadings(caseIandcaseII)andthesubsequentinspection
havebeencompletedwithoutndinganydefectsinthestructureorstabilityofthelift,the
lift may be used inside the permitted operating range presented in the reach/platform load
diagram of this manual.
The max. allowed platform load is 215 kg.
Inconjunctionwiththerst,i.e.start-upinspection,eachliftissubjectedtoatestloadingwith
an overload of 50% and after that the supporting structures are thoroughly inspected.
4.3.18. Inspection of the anti-corrosion treatment
Ifneeded,repeattheanti-corrosiontreatmentusinge.g.Tectyl210Ranti-corrosionagent.
