primary harness (H1) wiring diagram
______
______
______
______
______
______
______
______
______
4-pin satellite harness diagram
______
______
______
______
PINK IGNITION TRIGGER
PURPLE STARTER TRIGGER
ORANGE ACCESSORY TRIGGER
BLUE STATUS OUTPUT
1
2
3
4
WHITE (+/-) LIGHT FLASH
BLACK GROUND
RED/WHITE NOT USED
WHITE/RED (+) ACTIVATION INPUT
GRAY/BLACK (-) WAIT TO START INPUT
WHITE/BLUE (-) ACTIVATION INPUT
YELLOW IGNITION OUT (TO ALARM)
GREEN/WHITE FACTORY REARM
LIGHT GREEN/BLACK FACTORY DISARM
H1/1
H1/2
H1/3
H1/4
H1/5
H1/6
H1/7
H1/8
H1/9
To Next Page
