Directed Electronics 561T User Manual

© 2003 Directed Electronics, Inc. Vista, CA 11
heavy gauge relay satellite wiring diagram
______
______
______
______
______
______
remote start harness (H2) wiring diagram
______
______
______
______
______
BLUE/WHITE (-) 200 mA 2ND STATUS/REAR DEFOGGER OUTPUT
GRAY (-) HOOD PINSWITCH SHUTDOWN WIRE
BROWN (+) BRAKE SWITCH SHUTDOWN WIRE
VIOLET/WHITE TACHOMETER INPUT WIRE
BLACK/WHITE (-) NEUTRAL SAFETY SWITCH INPUT
H2/1
H2/2
H2/3
H2/4
H2/5
RED (+) (30A) HIGH CURRENT 12V INPUT
PINK/WHITE (+) PROGRAMMABLE OUTPUT FOR ACCESSORY OR IGNITION
RED (+) (30A) HIGH CURRENT 12V INPUT
ORANGE (+) (30 AMP) OUTPUT TO ACCESSORY CIRCUIT
PURPLE (+) (30 AMP) OUTPUT TO STARTER CIRCUIT
PINK (+) (30 AMP) OUTPUT TO IGNITION CIRCUIT
1
2
3
4
5
6
