21
© 2008 Directed Electronics. All rights reserved.
H2/3
WHITE/VIOLET (-) 200mA AUX 1 OUTPUT
This wire provides 200 mA programmable output whenever the transmitter but-
tons controlling Aux 1 channel is pressed. (See descriptions for Aux 3)
Warning! Never use this wire to drive anything
but a relay or a low-current input, supplied
output is only 200mA. Connecting directly to
a solenoid, motor, or other high-current device
will cause the module to fail.
H2/4
VIOLET/BLACK (-) 200mA AUX 2 OUTPUT
This wire provides 200 mA programmable output whenever the transmitter but-
tons controlling Aux 2 channel is pressed. (See descriptions for Aux 3.)
Warning! Never use this wire to drive anything
but a relay or a low-current input, supplied out-
put is only 200mA. Connecting directly to a
solenoid, motor, or other high-current device will
cause the module to fail.
H2/5
WHITE/BLACK (-) 200mA AUX 3 OUTPUT
This wire provides 200 mA programmable output whenever the transmitter
button(s) controlling Aux 3 is pressed. This output can be programmed to provide
the following types of outputs
Validity: Output that sends a signal as long as the transmission is re-•
ceived.
Latched: Output that sends a signal when the Aux channel button is pressed •
and continues until the same button is pressed.
