31
© 2008 Directed Electronics. All rights reserved.
Plug-in LED and valet/program switch
The LED and valet switch are incorporated into the control center the LED line
will plug into the white 2-pin port and the Valet switch line will plug into the blue
2-pin port.
Note
:
Onboard LED and valet switch can be substituted with an optional out-
board LED (P/N 8634 for Blue LED and 8633 for red LED) and an outboard
valet switch (P/N 8631).
Bitwriter interface - 3-pin black plug
The black 3-pin port is provided for programming the unit using the Bitwriter
(p/n 998T). When using the Bitwriter, it is possible to configure any and all of
the programmable functions as well as lock the Remote Control and System Fea-
tures Learn Routines so that unauthorized users cannot change the configuration
or program remote controls to the unit.
When the learn routines have previously been programmed using the
Bitwriter, they may have been locked. Before proceeding with repro-
gramming the learn routines, they must be unlocked with the Bitwriter
- this cannot be done manually with the Valet switch.
Note
:
Bitwriters require software v2.6. Bitwriters with date code of 6A or older
require an IC upgrade (p/n 998M). Some bitwriters with a date code of 6B do
not require the IC upgrade, refer to Tech Tip # 1112 for more information.
Bitwriter 2 compatible.
