➤ Remote start auxiliary output, 5-pin

These signals are provided to drive additional optional relays.

PINK/WHITE (-) 200mA FLEX RELAY CONTROL OUTPUT

This wire is programmed as (-) 2nd ignition output from factory and can be

programmed (to drive a relay) as a (-) starter or an accessory output. (See

Feature programming Menu 3, feature 8.)

ORANGE (-) 200mA ACCESSORY OUTPUT

This wire works like the main accessory wire and can be used (with a relay) to

drive any additional accessory circuits in the vehicle.

VIOLET (-) 200mA STARTER OUTPUT

This wire works like the starter wire and can be used (with a relay) to drive any

additional starter circuits in the vehicle.

PINK (-) 200mA IGNITION 1 OUTPUT

This wire works like the ignition 1 wire and can be used (with a relay) to drive

any additional ignition circuits in the vehicle.

Note: Wires 1 - 4 on the remote start auxiliary outputs are wired to the (-) triggers

for the onboard remote start relays and are not diode isolated. If connecting

these wires directly to the vehicle you must place a 1-amp diode in line to pre-

vent feedback from the vehicle.

BLUE (-) 200mA STATUS OUTPUT

This wire supplies an output as soon as the module begins the remote start pro-

cess. It can be used to activate a bypass module or power the key sense wire

in most vehicles to disarm the factory alarm without unlocking.

Note: Check vehicle information to verify if a bypass module is needed or if the

key sense wire is needed.
