Remote start auxiliary output, 5-pin
1
PINK/WHITE (-) 200mA FLEX RELAY CONTROL OUTPUT
2
ORANGE (-) 200mA ACCESSORY OUTPUT
3
VIOLET (-) 200mA STARTER OUTPUT
4
PINK (-) 200mA IGNITION 1 OUTPUT
5
BLUE (-) 200mA STATUS OUTPUT
Note: Wires 1 - 4 on the remote auxiliary outputs are wired to the (-) triggers for
the onboard remote start relays and are not diode isolated. If connecting these
wires directly to the vehicle you must place a 1-amp diode in line to prevent
feedback from the vehicle.
Door lock harness, 3-pin connector
1
BLUE (+) LOCK (-) UNLOCK OUTPUT
2
EMPTY NOT USED
3
GREEN (-) LOCK (+) UNLOCK OUTPUT
