Directed 933.TL16

6
933.TL16 1.03.198.9 2019 Toyota RAV4
©2023 Directed. All rights
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
Wiring diagram
TPMS Ignition Interrupt (veh. side): Blue/White: 1
TPMS Ignition Interrupt (conn. side): Blue: 3
Immo. Data Interr. (veh. side): Lt. Green: 8
Immo. Data Interr. (conn. side): Lt. Green/White: 9
(-) Ground: Black: 10
HS CAN Low 1: Tan: 1
(+) Ignition Output: White: 7
(+) Starter Output: Violet/Black: 8
Immo. Data: Dk. Blue/Black: 9
RDA: Orange/Black: 7
IMI (vehicle side): Yellow/Black: 8
HS CAN High 1: Tan/Black: 2
Siren
(+) 12V Input: Red: 6 & 12
Immo. Data: Black/White: 17
(+) Siren Output: Brown/Red: 11
(-) GWA Output: Blue/White: 2
Hood Pin
(-) Hood Input: Gray: 21
Security Only
Mandatory Connections
Remote Start Only
Legend:
Remote Start + Security
22 812
4 2442
Slide to open
A module can also be used for
this installation.
IMPORTANT:
Position the
fuses correctly!
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
MAIN (5A) (+)
(-) RLY3/PK LIGHT(15A) (+)
5
5
30
20
20
HS CAN Low: Violet, pin 4
HS CAN High:
Tan, pin 5
RDA: Red, pin 10
Body ECU
Connector
Body ECU Connector
(lower conn. left side
of steering column)
Body ECU
(middle conn. left side of steering column)
678
111213
1415161718
9
10
21 20 19
12
3
45
678
1112131415161718
9
10
30
2122
232425262728
20
19
29
12345
1
2
1
2
3
Refer to the
Starter disable connection
section for relay and
connector details.
12345678
Ignition
Connector
(+) Ignition:
Lavender/Red,
pin 8
(+) 12V:
Lavender/White,
pin 7
(+) Starter:
Lavender/Violet, pin 5
9 8 7 6 5 4 3 2
19 18 17 16 15 14 13 12
1
11
10
20
TPMS Connector
(white or blue conn. in passenger kick)
IMO/IMI Connector
(white conn. left of
dash fusebox)
10 9 8 7 6 5 4 3
19 18 17 16 14
2
13
1
12
11
20
TPMS Interrupt:
Lavender/Black or Lt. Green,
pin 12
Cut
15
IMO: Pink, pin 15
Cut
IMI: Red or Green,
pin 13
