Directed 933.TL16

9
933.TL16 1.03.198.9 2019 Toyota RAV4
©2023 Directed. All rights
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H2/18 Orange/Black No Connection No Connection
H2/19 Blue No Connection No Connection
H2/20 Green No Connection No Connection
H2/21 Gray
(-) Hood Switch Input [1]
The installation of an aftermarket hood pin is only required on vehicles
that are not equipped with a factory hood pin, or if not supported in
data.
Mandatory
H2/22 Violet/White No Connection No Connection
Main harness, 12-pin black connector (H3)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H3/1 Blue/White
Relay N.C. TPMS Ignition Interrupt (vehicle side) [3]
Passenger Kick, white or blue 20 pin plug (GM2), pin 12 Cut Lavender/Black or Lt. Green
(TPMS)
Remote Start
Only
H3/2 Blue/Red Relay N.O. No Connection No Connection
H3/3 Blue Relay COM. TPMS Ignition Interrupt (connector side)
[3]
Passenger Kick, white or blue 20 pin plug (GM2), pin 12 Cut Lavender/Black or Lt. Green
(TPMS)
Remote Start
Only
H3/4 White/Brown Relay N.C. No Connection No Connection
H3/5 White Relay COM. No Connection No Connection
H3/6 Red (+) 12 Volt Input Ignition Switch, white 8 pin plug, pin 7 + Lavender/White (7.5A)
Mandatory
H3/7 Lt. Green/Red Relay N.O. No Connection No Connection
H3/8 Lt. Green Relay COM. Immo Data Interrupt (vehicle side) Left of Dash Fuse Box, white 20 pin plug (AG4), pin 13 Data Red or Green (IMI)
Remote Start
Only
H3/9 Lt. Green/White Relay N.C. Immo Data Interrupt (connector side) Left of Dash Fuse Box, white 20 pin plug (AG4), pin 13 Data Red or Green (IMI)
Remote Start
Only
H3/10 Black (-) Ground (chassis ground)
Mandatory
H3/11 White Relay COM. No Connection No Connection
H3/12 Red (+) 12 Volt Input Ignition Switch, white 8 pin plug, pin 7 + Lavender/White (7.5A)
Mandatory
Relay harness, 10-pin white connector (H4)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H4/1 N/A No Connection No Connection
H4/2 Red/Black No Connection No Connection
H4/3 Pink/Black No Connection No Connection
H4/4 Pink/White No Connection No Connection
H4/5 Red No Connection No Connection
H4/6 Green No Connection No Connection
H4/7 Violet No Connection No Connection
H4/8 Orange No Connection No Connection
H4/9 Red/White No Connection No Connection
