CHAPTER 6: Technical Data
CHAPTER 6: Technical Data
Dimensions
• Width 19’’ (483 mm)
• Height 2 RU (89 mm)
• Depth 10’’ (254 mm)
Weight
• about 4 kg
Power Consumption
• typical 0.2 A (@84 V) up to max. 0.1 A (@264 V)
• max. 0.4 A (@84 V) up to max. 0.2 A (@264 V)
Power Supply
• 84 V - 264 V AC / 47 Hz - 63 Hz / Safety class 1
Fuses
• Fuse 250 V - 2 A (slow-blow) – 2 fuses per power supply
Environmental Conditions
• Operating temperature +5°C up to +45°C
• Relative humidity: 10% - 80%, non condensing
MADI Port - coaxial
• 16 x BNC socket (8 x input / 8 x output)
• Impedance: 75 Ω
• 0.3 V up to 0.6 V (peak to peak)
MADI Port - optical SC
• 8 x SC socket FDDI (input / output)
• ISO/IEC 9314-3
• Wave length: 1310 nm
• Multi mode 62.5/125 µm or 50/125 µm
• optional: single mode 9/125 µm
MADI Port - SFP
• 8 x SFP cage without module
• Wave length: depending on used transceiver (typical 1310 nm)
• Multi mode 62.5/125 µm or 50/125 µm
• Single mode 9/125 µm
Sample Rate
• 30 kHz - 50 kHz @ 1 FS
• 60 kHz - 100 kHz @ 2 FS
• 120 kHz - 200 kHz @ 4 FS
