CHAPTER 1: Overview
Feature Summary
MADI I/Os 2 x slots with eight MADI ports each
Module types: coaxial (BNC), optical SC (multi-mode)
and SFP (multi-mode)
single-mode upon request
MADI Formats 56/64 channel, 48k/96k Frame, S/MUX 2/4
Sample Rates 30 kHz to 50 kHz
(and their multiples - 2FS, 4FS)
Clock Inputs 1 x Word clock coaxial BNC
75 Ω termination switchable
1 x Video coaxial BNC
75Ω termination switchable
Black Burst (PAL, NTSC)
Clock Outputs 2 x Word clock coaxial BNC
Serial Data / MIDI 1 x RS232 DSUB-9
1 x RS422/485 DSUB-9
1 x MIDI in/out (DIN)
GPO 4 x GPO DSUB-9
Device Monitoring SNMP v1/v2
Device Mirroring Doppelgaenger Mode
Control Plug-Ins Telnet,Pro-Bel SWP-08 (network and serial), MIDI,
Jupiter, JSON
USB Port USB 2.0 port for virtual COM port (RS 232)
Power Supply This device is equipped with two wide range power
supplies (84 V to 264 V AC / 47 Hz to 63 Hz / safety
class 1)
Applications
M.1K2 can be used for distribution and creation of whole MADI streams, routing
of single audio channels between MADI streams and independent routing of
embedded serial data and MIDI data.
Typical applications include:
• distribution of audio signals in OB van with integrated switching protocol (e.g.
SWP08)
• central switch in studio environments - PolySync™ and browser control
• connection between remote mic preamps and mixing consoles (serial matrix)
• show control using snapshots
• fallback system - port redundancy, device mirroring
• ...
