User Manual –Wireless Video Bridge Gen 2
Version 1.0.0 12/16/2016 Page 7
II. H
ARDWARE
I
NFORMATION
A. W
IRELESS
V
IDEO
B
RIDGE
1. Front Panel
FIGURE 1: WVB - FRONT PANEL
The front panel contains
• Multicolor status indicator LED.
The WVB2 is to be installed vertically (It is not to be placed in horizontal position)
The WVB2 can be wall-mounted using the mounting bracket provided. When using the
mounting bracket, the WVB2 should remain positioned upright (not upside down).
2. Rear Panel
