Distech Controls ECL/ECB-PTU Series User Manual

Subnetwork Installation Guidelines
Network Guide 71
Subnetwork Module Compatibility and Supported Quantity
Charts
Not all subnetwork modules work with all controller models: The subnetwork module compati-
bility for an individual controller is shown in the table below along with the maximum supported
quantity of room devices and extension modules. The Subnet ID address of all subnet devices
must be set to be within the shown addressing range.
Adding devices to the subnetwork decreases system responsiveness which may
cause delays executing commands needing a fast response such as lighting and
shades/sunblind commands.
Table 16: Subnetwork Module Compatibility and Maximum Supported Quantity Chart
Controller
Model
Subnetwork Data Bus Device
Permitted Subnet
ID Addressing
Range
1
Maximum
Quantity Allowed
ECL-VAV
ECB-VAV
Allure EC-Smart-Vue series 1 to 4
See below
2
,
4
Allure EC-Smart-Comfort series 1 to 4
Allure EC-Smart-Air sensor series
EC-Multi-Sensor series 1 to 4
ECx-Light-4 / ECx-Light-4D / ECx-
Light-4DALI
1 to 4
ECx-Blind-4 / ECx-Blind-4LV
ECx-4XX I/O Extension Modules - Not Supported
ECx-Display - Not Supported
ECL-VAVS
ECL-VAV-N
ECB-VAVS
ECB-VAV-N
Allure EC-Smart-Vue series 1 to 4
4
3
Allure EC-Smart-Comfort series 1 to 4
Allure EC-Smart-Air series
EC-Multi-Sensor series - Not Supported
ECx-Light-4 / ECx-Light-4D / ECx-
Light-4DALI
- Not Supported
ECx-Blind-4 / ECx-Blind-4LV - Not Supported
ECx-4XX I/O Extension Modules - Not Supported
ECx-Display - Not Supported
