96 Network Guide
Figure 63: Typical ECx-4XX I/O Extension Module Address DIP Switch Set to 2
Power Supply Requirements
The ECB-600/ECL-600 and each associated ECx-4XX I/O Extension Module must have their
own dedicated power supply. To size the power supply transformer, see:
• Transformer Selection and Determining the Maximum Power Run Length on page 43 for
ECB-600 controllers.
• Transformer Selection and Determining the Maximum Power Run Length on page 61 for
ECL-600 controllers.
