How to Set a Dip Switch
Network Guide 131
APPENDIX B
How to Set a Dip Switch
DIP switches are used to set the address of a device. In the following table, A & B represent
the binary ON / OFF setting for the DIP switch required for a given decimal value shown in the
table.
B
A
000 001 010 011 100 101 110 111
0000
01234567
0001
8 9 10 11 12 13 14 15
0010
16 17 18 19 20 21 22 23
0011
24 25 26 27 28 29 30 31
0100
32 33 34 35 36 37 38 39
0101
40 41 42 43 44 45 46 47
0110
48 49 50 51 52 53 54 55
0111
56 57 58 59 60 61 62 63
1000
64 65 66 67 68 69 70 71
1001
72 73 74 75 76 77 78 79
1010
808182 8384858687
1011
88 89 90 91 92 93 94 95
1100
96 97 98 99 100 101 102 103
1101
104 105 106 107 108 109 110 111
1110
112113114115116117118119
1111
120 121 122 123 124 125 126 127
