Controls - 34 JT520 Operator’s Manual
750/752 Display
CMW
2. Pitch/slope indicator
and percentage
indicator
Indicates pitch beacon
percent of grade.
Internal: shows pipe label and stored
pitch.
External: shows desired pitch.
3. Roll indicator Indicates beacon roll angle.
4. Target identifier
indicator
Indicates approximate
beacon location.
Only one set of arrows is active at a
time.
5. Depth estimate Indicates beacon depth
estimate.
Internal: shows job number and
stored depth.
External: shows desired depth.
