JT520 Operator’s Manual Controls - 35
750/752 Display
CMW
6. Display battery status
indicator
Indicates display power from
drilling unit.
If all five bars are not showing, check
display power connections.
7. Beacon battery status
indicator
Indicates beacon battery
status.
See beacon instruction sheet.
8. Beacon temperature
indicator
Indicates beacon
temperature.
See beacon instruction sheet.
Item Description Notes
