Specifications - 94 XT1600 Operator’s Manual
CMW
Power U.S. Metric
Engine: Kubota V2003-M-DI-TE2B diesel
Cooling medium: liquid coolant (see “Approved Coolant” on page 76)
Number of cylinders: 4
Injection: direct
Displacement
112 in
3
1835 cm
3
Bore 3.27” 83 mm
Stroke 3.64” 92.4 mm
* Maximum tilt angle, fore and aft 30° 30°
* Maximum tilt angle, side 30° 30°
Installed net power per SAE J1349 (@ 2800 rpm) 53 hp 39.5 kW
Gross power per SAE J1995 59 hp 44 kW
Maximum governed speed (no load, standard unit) 3000 rpm 3000 rpm
Maximum governed speed (no load, EC-compliant unit) 2800 rpm 2800 rpm
* Exceeding these operating angles will cause engine damage. This DOES NOT IMPLY machine is stable to maximum angle of
safe engine operation.
Fluid Capacities U.S. Metric
Fuel tank 20 gal 75.7 L
Engine oil, with filter 8 qt 7.6 L
Hydraulic tank 16 gal 60.6 L
Hydraulic system 21 gal 79.5 L
