LED ON Flashing
POWER ALARM 24 V= power supply. Encoder / automation fault.
IN During the commands: 1-3A, 1-3B, 27-3A, 27-3B. Flashes once each time the dip switch and command
1-2 status changes.
SA Safeties 41-6 and 41-8 open. Safety test failure.
2.10 Signals
2.9 Jumper
Description OFF ON
J1 Integrated photocell. Disabled. Enabled.
J2 FUTURE USE / /
J3 Safety test terminal 41. Disabled. Enabled.
3. STARTING
ATTENTION: Before performing any type of operation, make sure that the automation is turned off and the batteries are
disconnected.
The operations related to point 3.4 are performed without safeties.
The trimmer can only be adjusted with the automation idle.
3.1 Select the correct direction with DIP2.
3.2 Set trimmer TC to the minimum and trimmers VA, VC, RP, R1 halfway.
3.3 Make a jumper on the safeties (41-6 and 41-8) and the stop (1-9). Set J1=OFF.
3.4 Turn on (mains and batteries). SETTINGS RESET with the OPEN button as indicated in paragraph 2.4.
Attention: the control panel performs an automatic POWER RESET on each start and the first opening or closing manoeuvre
is performed at low speed allowing the automatic self-learning of the stop positions (acquisition).
Check that the automation is operating correctly with further opening and closing commands and set the desired speed with
VA and VC.
3.5 Adjust the thrust on obstacles with trimmer R1.
3.6 Remove the jumper and connect the safeties (41-6 and 41-8) and the stop (1-9). If the CELPR photocells are present, set
J1=ON.
3.7 Select the battery function with DIP3 and DIP4.
3.8 Adjust the automatic closing with the TC (enabled by command 1-2).
3.9 Set the partial opening with RP if required.
3.10 Connect possible accessories and check they are functioning.
3.11 If the automation encounters an obstacle during closure, it is detected and the automation opens again.
If the automation encounters an obstacle during opening, it is detected and the automation stops.
If the obstacle is detected twice in a row, it is considered as the new stop until it is removed.
Warning: check the operating force and that the contact force between the door and the obstacle is lower than that indicated
by the DIN 18650-1 standard.
