1592001850 XC660D GB r3.4 04.09.2017.docx XC660D 32/55
17.12 Analog output 1 (optional) – Terminals 25-26
AoC Analog output 1 setting
tEn = 0÷10V output
cUr = 4-20mA output
AOF Analog output 1 function
nu = analog output disabled;
Inc1= To drive inverter for suction frequency compressor, suction of circuit 1;
Inc2 = To drive inverter for suction frequency compressor, suction of circuit 2
inF= to drive ECI fan or inverter for fan
FrE = “Free”, proportional to the probe P3 and P4.
InCP Inverter compressor always activated at first:
no: other compressors if available are allowed to start when the inverter compressor is
locked by safety timers. This allows the system to satisfy the cooling demand when the
inverter compressor is unavailable.
yES: the inverter compressor is always started as first. If unavailable due to safety timers
the regulation will be locked till timers will be over.
AOP Reference probe for the analog output 1 It is used only if AOP=FrE
nP = not probe
P3 = probe P3
P4 = probe P4
LAO Temperature value associated to minimum value of analog output (AOM)
(-50.0÷150.0°C, -58÷302°F).
UAO Temperature value associated to the maximum value of analog output, 10V or
20mA (-50.0÷150.0°C, -58÷302°F).
AOM Minimum value for analog output 1 (4 ÷ 20mA or 0÷10V)
AOt Time of analog output 1 at max after the start (0÷15s)
MPM Maximum % variation per minute of analog output 1: (nu; 1÷100)
nu = not used: function disabled
1÷100 = it sets the maximum percentage variation per minute of the analog output.
SAO Percentage of analog output 1 in case of probe failure: (0 ÷ 100%)
AOH Maximum analog output 1 percentage when silence mode function is enabled
(0÷100)
17.13 Analog output 2 (optional) – Terminals 27-28
2AoC Analog output 2 setting
tEn = 0÷10V output
cUr = 4-20mA output
2AOF Analog output 2 function
nu = analog output disabled;
Inc1= To drive inverter for suction frequency compressor, suction of circuit 1;
Inc2 = To drive inverter for suction frequency compressor, suction of circuit 2
inF= to drive ECI fan or inverter for fan
2AOM Minimum value for analog output 2 (4 ÷ 20mA or 0÷10V)
2AOt Time of analog output 2 at max after the start (0÷15s)
2MPM Maximum % variation per minute for analog output 2: (nu; 1÷100)
nu = not used: function disabled
1÷100 = it sets the maximum percentage variation per minute of the analog output.
2SAO Percentage of analog output 2 in case of probe failure: (0 ÷ 100%)
2AOH Maximum analog output 2 percentage when silence mode function is enabled
(0÷100)
