dixell XC660D User Manual

1592001850 XC660D GB r3.4 04.09.2017.docx XC660D 48/55
Code
Description
Cause
Action
Reset
E0H
High
pressure
switch alarm
High pressure
switch input
enabled
- All
compressors
are turned off.
- All fans are
turned on.
Automatically (if the number of activation are
less than PEn in the PEi time) when the input is
disable.
- Compressors and fans restart working
according to the working algorithm.
Manually (if PEn activation happened in the PEi
time)
When the input is disable:
- hold pressed the Restart(DOWN) key for
3s or
- turn off and on the instrument.
Compressors and fans restarts working according
to the working algorithm.
P1
P1 probe
failure alarm
Probe failure or out
of range
 The
compressors
are activated
according to the
SPr or PoPr
parameters.
Automatically as soon as the probe restarts
working.
P2
P2 probe
failure alarm
Probe failure or out
of range
 The fans are
activated
according to the
FPr
parameters.
Automatically as soon as the probe restarts
working.
P3
P3 probe
failure alarm
Probe 3 failure or
out of range
 With P3 used
for circuit 2, the
compressors
are activated
according to the
2SPr.
 The functions
related to the
third probe are
disabled.
Automatically as soon as the probe restarts
working.
P4
P4 probe
failure alarm
Probe 4 failure or
out of range
 The functions
related to the
fourth probe are
disabled.
Automatically as soon as the probe restarts
working.
EA1
EA2
EA3
EA4
EA5
EA6
Load safeties
alarm
Safeties
compressor/fan
input activation.
NOTE: with step
compressors 1
input for each
compressor has to
be used.
 the
corresponding
load is turned
off. (with step
compressors all
relays referred
to the input are
disabled).
Recovery depends on ALMr parameter:
With ALMr = no The instrument restart the
standard operating mode when the input is
disabled.
With ALMr = yES manual recover for the alarms
of compressors and fans. Push the DOWN key for
3s.
C1-LA
Minimum
pressure
(temperature)
alarm
compressors
section
Suction pressure or
temperature lower
than
LAL value
signaling only
Automatically: as soon as the pressure or
temperature reaches the (LAL+ differential) value.
(differential = 0.3bar or 1°C)
