MAJOR COMPONENT DESCRIPTION
25
AC DISTRIBUTION BOX
DN35##
110 VAC and 220 VAC units
Main Power Switch / Plug Interrupts hot side
of incoming power
to all components in
machine.
15 Amp Outlet (110 VAC) Provides power to
15 Amp Outlet (220 VAC) refrigeration unit.
Transformer (T1) Provides 24 Volt
and 12 Volt (center
tap) power to the
Controller Board.
Fuse (X2 Center) 2 Amp SloBlo;
protects primary of
T1.
Fuse (X3 Left Side) 10 Amp, 32 Volt,
SloBlo; protects 24
Volt input to
Controller Board
from secondary of
T1.
Fuse (X4 Right Side) 2 Amp, SloBlo;
protects 12 Volt
input to Controller
Board from
secondary, center
tap of T1.
Varistor Across incoming AC power to remove large
power spikes.
REFRIGERATION UNIT
DN35##
110 VAC units
Compressor Aspera, 1/2 HP, 115 VAC,
60 Hz, 1 Phase
T6213Z
Unit uses 13 oz. of 134A
refrigerant
Start Relay 110 VAC – T1 9660-041-
180
Double Pole, 115 VAC
Start Capacitor 110 VAC - 189227
Thermal Overload 110 VAC - TI MST16AFN-
3001
Condenser Fan 16W Motor
110 VAC – FV100CW25S
Blade - 10” dia.
Evaporator Fan Motor
110 VAC - SPGE9HBV1
Blade - 8” dia.
