VENDER SAFETY PRECAUTIONS
Please read this manual in its entirety. This service
information is intended for use by a qualified service
technician who is familiar with proper and safe
procedures to be followed when repairing, replacing or
adjusting any Dixie-Narco vender components. All
repairs should be performed by a qualified service
technician who is equipped with the proper tools and
replacement components, using genuine Dixie-Narco
factory parts.
REPAIRS AND/OR SERVICING
ATTEMPTED BY UNQUALIFIED
PERSONS CAN RESULT IN
HAZARDS DEVELOPING DUE TO
IMPROPER ASSEMBLY OR
ADJUSTMENTS WHILE
PERFORMING SUCH REPAIRS.
PERSONS NOT HAVING A PROPER
BACKGROUND MAY SUBJECT
THEMSELVES TO THE RISK OF
INJURY OR ELECTRICAL SHOCK
WHICH CAN BE SERIOUS OR EVEN
FATAL.
IMPORTANT NOTE: This machine should not be
used to vend perishable
products without the Health
Control Kit (622,010,200.04)
installed. If you wish to vend
perishable products, please
contact Dixie-Narco for
assistance.
PRODUCT IDENTIFICATION
The age of Dixie-Narco products is determined by the
date code incorporated in the serial number.
The vender serial number takes the form xxxx-yyyy
zz. The first 4 digits (xxxx) identify the specific
vender. The next 4 digits (yyyy) identify the
manufacturing run that the vender was built in. The
last two alpha characters (zz) identify the quarter and
the year the vender was built. The first alpha
character identifies the quarter as follows:
A= 1
st
Quarter
B= 2
nd
Quarter
C= 3
rd
Quarter
D= 4
th
Quarter
The second alpha character identifies the year:
W = 1998
X = 1999
Y = 2000
Z = 2001
A = 2002
B = 2003
C = 2004
PHYSICAL CHARACTERISTICS
DN 2145
HEIGHT
72” (1828.8 mm)
WIDTH
42” (1066.8 mm)
DEPTH
32” (812.8 mm)
BASE
6” (152.4 mm)
SHIPPING WEIGHT
622 lbs. (282 kg)
Glass door is 30” (762 mm) wide, 52” (1320.8 mm)
high
DN 55##
HEIGHT
72” (1828.8 mm)
WIDTH
43” (1092.2 mm)
DEPTH
32” (812.8 mm)
BASE
4.5” (114.3 mm)
SHIPPING WEIGHT
694 lbs. (314.8 kg)
Glass door is 33” (838.2 mm) wide, 56” (1422.4 mm)
high
DN 35##
HEIGHT
72” (1828.8 mm)
WIDTH
32.5” (825.5 mm)
DEPTH
32” (812.8 mm)
BASE
4.5” (114.3 mm)
SHIPPING WEIGHT
545lbs. ( 246.9 kg)
Glass door is 23.08” (586.23 mm) wide, 56” (1422.4
mm) high
