4
RECEIVING INSPECTION
DO NOT STORE THE VENDER OUTSIDE.
Upon receipt, inspect the vender for any shipping
damage. If there is any damage, have the delivery
driver note the damage on the bill of lading and notify
Dixie-Narco. Although the terms of sale are FOB
shipping point, which requires the consignee to
originate shipping damage claims, Dixie-Narco will
gladly help if you must file a claim.
UNPACKING THE VENDER
Remove the stretch wrap, fiberboard edge protectors
and corrugated front protector from the outside of
vender.
Do not store the vender with stretch
wrap on. Stretch wrap could bond to
the vender’s surface, which could
damage the finish.
Remove the shipping boards from the bottom of the
vender. The shipping boards are attached by the
leveling legs. To avoid unnecessary damage to the
leveling legs or base, remove the shipping boards by
using a 1-1/2 inch socket type wrench to unscrew the
leveling legs. Be sure to replace the legs after
removing the shipping boards.
Once the vender is unpacked, check the recovery unit
for any additional parts, price/ product labels,
service/operation manual or other information
concerning factory-equipped accessories such as coin
mech and validator.
WARNING: TO AVOID THE
POSSIBILITY OF A FIRE
HAZARD, DO NOT STORE
ANYTHING OR ALLOW DEBRIS
OF ANY KIND TO ACCUMULATE
IN THE BOTTOM OF THE
SERVICE AREA, IN AND
AROUND THE REFRIGERATION
COMPARTMENT OF THE
CABINET, OR IN FRONT OF
THE EVAPORATOR AND
CONDENSER COILS.
ELECTRICAL POWER NEEDED
Refer to the cabinet serial number plate to determine
the proper voltage and frequency the machine
requires (domestically, this requirement is 120 VAC,
60 Hz). The cabinet serial plate also indicates the
amperage of the vender. The vender must be
plugged into its own properly rated single phase,
alternating current outlet with its own circuit protection
(fuse/circuit breaker).
DO NOT USE AN EXTENSION CORD.
GROUND THE VENDER
The vender is equipped with a three-wire power
supply cord and MUST be plugged into a properly
grounded outlet.
DO NOT REMOVE THE GROUND
PIN OR IN ANY WAY BYPASS,
MODIFY, DEFEAT, OR DESTROY
THE GROUNDING SYSTEM OF
THE VENDER.
If the outlet will not accept the power cord plug,
contact an electrician to install a proper AC outlet.
FAILURE TO COMPLY WITH
THESE INSTRUCTIONS MAY
SUBJECT THE USER TO THE RISK
OF INJURY OR ELECTRICAL
SHOCK WHICH CAN BE SERIOUS
OR FATAL.
INSTALLATION AND SETUP
INSTRUCTIONS
Open the service door on the right side using the key
provided in the coin return cup, or if shipped with a
locking clip, remove the clip and install the lock.
Ensure there is no power to the AC Distribution Box.
On venders with a main power switch on the AC
Distribution Box the switch needs to be in the OFF
position. On venders with a main power quick
disconnect plug on the AC Distribution Box the quick
disconnect plug needs to be unplugged. Check that
all connectors are firmly seated on the control board
and at the various components on the service door
(coin mech, keypad, etc.).
Retrieve the main power plug from the hole in the rear
of the vender and plug the cord in a properly
grounded 120VAC, 15 Amp receptacle (U.S. and
Canada).
Open the service door and apply power to the AC
distribution Box (if equipped with a bill acceptor, the
acceptor should cycle twice). The display on the door
should scroll the message “USE EXACT CHANGE”,
the fluorescent lamp should be lit and the cooling unit
should start.
If the display scrolls “OUT OF SERVICE”, or the
cooling unit fails to start, refer to the
TROUBLESHOOTING FLOWCHARTS beginning on
page 29.
SERVICE NOTE
Battery Backup
The battery backup is used to retain information
programmed in the system (pricing, time, date, etc.).
in case of power interruptions, or any time the main
power is off. When the vender is shipped, the battery
is connected and memory is being maintained. If the
vender is to be stored for long periods of time,
disconnecting the battery is recommended. The
following steps will guide you through this procedure:
