Dixie Narco 55 Series - Page 59

ELECTRICAL DIAGRAMS & SCHEMATICS
58
CABINET DETAIL
INDEX
NUMBER PART NUMBER PART DESCRIPTION
1 622,070,02x.x3 Left Tray Mounting Bracket, Domestic DN 2145
622,050,35x.x3 DN2145, Export
627,070,21x.x3 DN5591/3591
627,070,08x.x3 DN5592/3592
627,070,12x.x3 DN5593
627,070,25x.x3
DN5594/3594
5
622,050,36x.x3 Mexico 600 ml DN2145
2 D042 Rear Tray Support Bracket, Domestic DN2145
622,050,33x.x3 Export DN2145
622,050,38x.x3 Mexico 600 ml DN2145
627,070,23x.x3 DN5591/3591
627,070,07x.x3 DN5592/3592
627,070,11x.x3 DN5593
627,070,27x.x3 DN5594/3594
3 622,070,03x.x3 Right Tray Mounting Bracket, Domestic 20 oz. DN2145
627,070,22x.x3 DN5591/3591
627,070,09x.x3 DN5592/3592
627,070,13x.x3 DN5593
627,070,26x.x3 DN5594/3594
622,050,34x.x3 Export DN2145
622,050,37x.x3 Mexico 600 ml DN2145
4A 627,020,11x.x3 DN55## /35## Security Angle Hinge, Left
622,060,06x.x3 DN2145 Security Angle Hinge, Left
4B 627,020,13x.x3 DN55## Security Angle Top
622,050,04x.x3 DN2145 Security Angle Top
635,020,06x.x3 DN35## Security Angle Top
4C 622,060,07x.x3 Security Angle, Right DN2145
627,020,12x.x3 Security Angle Right DN55##/35##
5A 804,100,77x.x1 Switch Door
5B 622,060,05x.x3 Door Switch Bracket
6A 801,903,56x.x1 Rear Plate
6B 622,050,39x.x3 Ingress Guard DN55##(Export not shown)
6C 635,050,13x.x3 Ingress Guard DN35##
7 622,020,08x.x3 Brace, Rear Base Plate
8A 622,041,10x.x3 Fan Assembly, Evaporator (115V 60 Hz, 9W)
622,041,00x.x3 Evaporator Fan Assembly (230V 50 Hz, 9W)
622,043,00x.x3 Evaporator Fan Assembly (220V 50 Hz)
8B 804,501,09x.x1 Evaporator Fan Motor (115 V / 60 Hz)
804,501,11x.x1 Evaporator Fan Motor (220-230 / 50 Hz)
