ELECTRICAL DIAGRAMS & SCHEMATICS
62
REFRIGERATION UNIT – TECUMSEH
DN 5500 / DN 5400 / DN 2145 – ROLL UP CONDENSER)
INDEX
NUMBER PART NUMBER PART DESCRIPTION
1A 804,501,19x.x1 Condenser Fan Assembly, 115 V / 60 Hz
804,501,10x.x1 Condenser Fan Assembly, 220-230 V / 50 Hz
1B F470 Condenser Fan Motor, 115 V 60 Hz 9W
F471 Condenser Fan Motor, 230 V 50 Hz 9W
1C F469 Condenser Fan Blade, 8” FV 800 CW 305
2 802,502,22x.x1 Compressor, 115 V / 60 Hz Aspera T6213Z ½ HP
W290 Compressor, 220 V / 50 Hz Tecumseh ½ HP
802,502,25x.x1 Compressor, 220-230 V / 50 Hz Aspera T6213Z ½ HP
3 802,500,94x.x1 Relay, 110 V – TI 9660-041-180
D609-2 Relay, 220 V - Tecumseh
802,502,27x.x1 Relay, 220 V – T1 9660-041-158
4 D610-1 Start Capacitor, 110 V – Tecumseh
D610-2 Start Capacitor, 220 V – Tecumseh
802,502,24x.x1 Start Capacitor, 189227 60 Hz
802,502,28x.x1 Start Capacitor, 250 V / 50 Hz (88-108MFD)
5 802,600,63x.x1 Evaporator
6 802,600,62x.x1 Condenser, Roll Up
7 D608-1 Overload, 110 V – Tecumseh
D608-2 Overload, 220 V – Tecumseh
802,502,23x.x1 Overload, T1, 115 V – Aspera (MST 16 AFN-3001)
802,502,26x.x1 Overload, T1, 220 V – Aspera (MRP 20APK-34)
8 609,044,20x.x4 Refrigeration Kit 115 V / 60 Hz
609,045,90x.x4 Refrigeration Kit 220 V / 50 Hz – Aspera 1620
9 622,041,20x.x3 Assy., Drain Pan Evaporator (not shown)
10 622,040,12x.x3 Drain Pan 1600 C-A Unit / 1620 C-A
11 804,601,48x.x1 Junction Box
12 802,401,30x.x1 Dryer (not shown)
13 801,817,41x.x1 Drain Tube
