ELECTRICAL DIAGRAMS & SCHEMATICS
64
REFRIGERATION UNIT – ASPERA
(DN 35## FIN & TUBE CONDENSER)
INDEX
NUMBER PART NUMBER PART DESCRIPTION
1A Refrigeration Unit 2001 C-A, 115V/60Hz Domestic Kit
1B 635,050,06x.x3 Refrigeration Unit 2001 C-A, 115V/60Hz Domestic
2 626,040,60x.x3 Compressor Assy. 115V/60Hz Domestic
2A 802,502,22x.x1 Compressor “A” T6213Z, Domestic
2B 626,041,30x.x3 Compressor “A” T6213Z, Export
3A 802,502,23x.x1 Overload, T1, 115V, MST 16 AFN-3001 Domestic
3B 802,502,26x.x1 Overload, T1, 220V, MRP 20APK-34 Export
4A 802,500,94x.x1 Relay, 110V – TI 9660-041-180 Domestic
4B 802,502,27x.x1 Relay, 220V – T1 9660-041-158 Export
5 802,502,01x.x1 Cover, Overload/Relay Tecumseh
6A 802,502,24x.x1 Start Capacitor, 110V – 189227 Domestic
6B 802,502,28x.x1 Start Capacitor, 250V/50Hz (88-108MFD) Export
7 802,501,18x.x1 Start Capacitor, End Cap Bottom Hole
8 802,501,87x.x1 Bracket, Capacitor Assembly
9A 801,812,61x.x1 Drain Pan, Condensate - Domestic
9B 801,813,55x.x1 Drain Pan, Condensate - Export
10A 626,040,70x.x3 Assembly Condenser Fan 16W, 10” Domestic
10B 626,041,40x.x3 Assembly Condenser Fan 16W, 22V Export
11A 804,501,14x.x1 Condenser Fan Motor, 16W Domestic
11B 804,501,18x.x1 Condenser Fan Motor, 16W Export
12 902,100,29x.x1 Silencer
13 801,305,67x.x1 Fan Blade, Condenser FV 100CW25S
14 900,800,85x.x1 Speed Nut
15 802,600,64x.x1 Condenser
16 802,401,30x.x1 Dryer
17 902,000,57x.x1 Grommet Compressor
18 802,600,63x.x1 Evaporator
19 802,401,35x.x1 Accumulator
